Blind Rivets
Types of Blind Rivets

Dome Head

Countersunk Head

Dome Head - Close End

Countersunk Head - Close End

Structural Rivets

Black Sealed Rivets

DIY Blind Rivets

Colorful Cover
REQUEST A QUOTE FOR MORE DETAILS
The Guide To Blind Rivets
Guide 1
What are the Rivets?
Rivet is a short metal pin or bolt for holding together two plates of metal, its headless end being beaten out or pressed down when in place.
Guide 2
Parts Name/Material of the Blind Rivet

Mandrel: The mandrel is that portion of a pull mandrel or threaded type blind rivet that is presassembled in the rivet body. During rivet setting the pulling or torquing of the mandrel is the action which forms the blind head. Mandrels usually are upset and may be smooth, sererated, or threaded.
Pin. A pin is that part of a drive pin type blind rivet which is preassembled in the rivet body, and that when forced completely into the body spreads the walls of the rivet end forming a head on the blind side.
The material combinations of break mandrel blind rivets are designated as grades, with each material combination representing a different combination of rivet body material and mandrel material as given in IFI 114.
Rivet bodies and mandrels shall be made of the material specified for the grade in the IFI 114. When the specific material analysis is not given, the analysis shall be selected by the manufacturer and shall be such to assure that rivets meet the mechanical and performance requirements specified in the IFI 114.
Guide 3
Blind Rivet Surface Treatment
Grade 30 rivet bodies are either zinc or cadmium plated with a minimum plating thickness of 0.00015 in. Rivet bodies of all other grades are furnished plain (bare metal) unless otherwise specified. Because mandrels are discarded following rivet setting, mandrels of all materials may be furnished plain or with a protective coating at the option of the manufacturer.
Guide 4
Designation of the Blind Rivet
INCH FASTENERS
Rivets shall be designated by the following data in the sequence shown:
(a) product name
(b) head style
(c) rivet material/stem material
(e) rivet diameter/length
(f) protective finish, if required
See the following examples:
EXAMPLES:
(1) Truss Head Plugged Rivet – Aluminium/Steel – 3/16″x5/16″
METRIC FASTENERS
Rivets shall be designated by the following data in the sequence shown:
(a) product name
(b) head style
(c) rivet material/stem material
(e) rivet diameter/length
(f) protective finish, if required
See the following examples:
EXAMPLES:
(1) Rivet DIN 7337 – A4 X 8 – Steel/Steel – A1
Guide 5
Inspection of Blind Rivets

Vernier Caliper
Will use vernier calipers to measure the basic dimensions of Rivets.

Tension Testing Machine
Will use the tension testing machine to measure the tensile strength of metric/inch Rivets.

Coating Thickness Gauge
Will use coating thickness gauge to measuere the thickness of the coating layer, such as zinc electoplated.
Guide 6
Packaging of Blind Rivets

Usual Packaging
Label: black text on white, no pattern and barcode
Carton: standard double corrugated neutral carton, bulking packing, maximum load bearing: 25kg per carton
Pallet: Europe Fumigation Pallet, 36 cartons per pallets, Width 800mm x Length 1200mm
Guide 7
Production Time of Blind Rivets

Flow 01: Need 3 Days – Analyze Customers’ PO and Place Orders to the Factory
Flow 02: Need 10 Days – Purchase the Raw Material
Flow 03: Need 15 Days – Make Production Plan and Wait for Starting Production
Flow 04: Need 15 Days – Formal Mass Production
Flow 05: Need 7 Days – Send Out to Do Heat Treatment (if exist)
Flow 06: Need 7 Days – Send Out to Do Surface Treatment (Finish)
Flow 07: Need 7 Days – Packaging, Make the Shipment
Total Time: 60 Days to 70 Days
Guide 8
Inquiry Required Content
Let us know who you are, and we can contact you in time.
We will give you a more reasonable price.
Let us know your needed product well.
Let us know if the products need to do the heat treatment.
Zinc Electoplated or Hot Dip Galvanized Coating or Zinc Flake Coating…
Our MOQ is about 1 pallet (900KGS) per size.
If it is a customized package, we will send the carton/label to you by courier for confirmation before packaging.
We will make a more suitable production plan for you.
FOB (We usually quote based on FOB ), CIF, FCA
This information is important before mass production. We will adjust the production plan according to your requirement.
